Home » Products » PoE Injector » 15W 35W PoE Injector Adapter IEEE802.3 Af At Active Injector for IP Camera Wireless AP WIFI 6
15W 35W PoE Injector Adapter IEEE802.3 Af At Active Injector for IP Camera Wireless AP WIFI 6
15W 35W PoE Injector Adapter IEEE802.3 Af At Active Injector for IP Camera Wireless AP WIFI 6 15W 35W PoE Injector Adapter IEEE802.3 Af At Active Injector for IP Camera Wireless AP WIFI 6
15W 35W PoE Injector Adapter IEEE802.3 Af At Active Injector for IP Camera Wireless AP WIFI 6 15W 35W PoE Injector Adapter IEEE802.3 Af At Active Injector for IP Camera Wireless AP WIFI 6
15W 35W PoE Injector Adapter IEEE802.3 Af At Active Injector for IP Camera Wireless AP WIFI 6 15W 35W PoE Injector Adapter IEEE802.3 Af At Active Injector for IP Camera Wireless AP WIFI 6
15W 35W PoE Injector Adapter IEEE802.3 Af At Active Injector for IP Camera Wireless AP WIFI 6 15W 35W PoE Injector Adapter IEEE802.3 Af At Active Injector for IP Camera Wireless AP WIFI 6
15W 35W PoE Injector Adapter IEEE802.3 Af At Active Injector for IP Camera Wireless AP WIFI 6 15W 35W PoE Injector Adapter IEEE802.3 Af At Active Injector for IP Camera Wireless AP WIFI 6

loading

15W 35W PoE Injector Adapter IEEE802.3 Af At Active Injector for IP Camera Wireless AP WIFI 6

Share to:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
◆AC input voltage range 90-264VAC
◆Protections against: short circuit/over current/over voltage
◆Average energy efficiency≥85%
◆Meet IEEE802.3 af/at standard
◆Support10Mbps/100Mbps/1G/2.5G/5G/10G Ethernet transmission
◆Meet 6KV surge immunity

  • PoE35-560062SPA

  • UE Electronic

  • 8504409999

  • USB-C

  • Foldable

  • Below 30W

  • None

  • 2

  • 3

  • USB-C to USB-C

  • American Standard

Availability:
Quantity:
Inquire Add to Basket

5W Active Gigabit PoE Injector – High-Power & Intelligent Power over Ethernet Solution

Product Overview

The UE Electronic 35W Active PoE Injector delivers reliable power and high-speed data transmission over a single Ethernet cable, eliminating the need for AC power outlets near your network devices. Engineered with active PD auto-detection, this injector delivers up to 35W of stable DC output, offering extended power headroom for demanding Powered Devices (PDs) such as PTZ IP cameras, Wi-Fi 6 Access Points, and IP phones.

With full Plug-and-Play functionality and comprehensive industrial-grade circuit protection, it provides a cost-effective, seamless infrastructure upgrade for both commercial and industrial networking applications.

Key Features :

  • Active Smart Detection: Built-in intelligent chip automatically detects and identifies connected PDs before supplying power, protecting non-PoE equipment from accidental damage.

  • 35W High-Power Output: Delivers up to 35W max output power, backward compatible with IEEE 802.3af/at standard devices with enhanced power margin.

  • Gigabit Data Speeds: Supports 10Mbps/100Mbps/1G/2.5G/5G/10G pass-through, ensuring full bandwidth for bandwidth-intensive devices like 4K HD surveillance and wireless APs.

  • 100m (328ft) Long-Distance Transmission: Power and data can be reliably transmitted simultaneously over Cat5e/Cat6 cables up to 100 meters.

  • Industrial-Grade Safety Protection: Features integrated Over-Current (OCP), Over-Voltage (OVP), Short-Circuit (SCP), and Surge Protection to ensure 24/7 continuous operation.

  • Compact & Durable Enclosure: High-strength, heat-resistant casing with flexible mounting options (desktop or wall-mount) for easy integration.


1 Input Characteristics


1.1 Voltage & Frequency



 Rated Minimum Maximum

Input Voltage

 100Vac-240Vac 90Vac 264Vac
Input Frequency 50Hz-60Hz 47Hz 63Hz

1.2 Current

Output Load Input Voltage Input Current
0-0.62A 100Vac 1.0A Max


2 Output Characteristics


2.1 Output rate

Model No. Output Voltage/Current Ripple & Noise(Max.) Line/ Load Regulation
POE35-560062SPA 56V±5%/0-0.62A 200mVp-p

200mVp-p

Remark： 1. Measurement is done by 20MHz bandwidth oscilloscope and terminated each output with a 0.1µF ceramic capacitor and a 10µF electrolysis capacitor.


3 Environment Requirements

Items Minimum Maximum Remark
Operating Temperature -25℃ 50℃
Storage temperature -20℃ 80℃
Relative Humidity 5% 90%
Altitude 0m 5000m
Cooling / / Nature Cooling
RoHS / / Comply with EU RoHS Directive requirement.

35w poe injector active injector poe injector for ip camera poe injector for WIFI 6 poe injector for Wireless AP 15W POE INJECTOR IEEE802.3 AF POE INJECTOR IEEE802.3 AT POE INJECTOR 35W POE INJECTOR FOR CCTV 35W POE INJECTOR FOR IP PHONE
